Hobby Zone Sport Cub S Instruction Manual

Instruction Manual • Bedienungsanleitung • Manuel d’utilisation • Manuale di Istruzioni®Sport Cub S

EN10®Sport Cub S SAFE™ Control Direction TestPerform the Control Direction Test to ensure the aircraft responds correctly to your transmitter. Once yo

RTFEN11Sport Cub S TakeoffHand LaunchUse the Beginner mode for takeoff in fi rst fl ights. Get help to hand launch your aircraft so you can concentrate

EN12®Sport Cub S FlyingIn Beginner mode, when properly trimmed, youraircraft will climb at full throttle without use of the elevator stick.• Set a fl

RTFEN13Sport Cub S Wind 0–5 mph (0–8 km/h)LandingFly to your runway, keeping the aircraft pointed into the wind and the wings level. Bring the aircraf

EN14®Sport Cub S Motor Service130 x 70CAUTION: DO NOT handle propeller parts while the fl ight battery is connected. Personal injury could result.Disas

RTFEN15Sport Cub S Optional FloatsTo fl y this aircraft off water, install the optional E-fl ite® Float Set (EFLUA1190, sold separately).A rear fl oat mo

EN16®Sport Cub S Troubleshooting Guide (SAFE™)ProblemPossible Cause SolutionControl surfaces not at neutral position when transmitter controls are at

RTFEN17Sport Cub S ProblemPossible Cause SolutionReduced fl ight time or aircraft underpoweredFlight battery charge is low Completely recharge fl ight b

EN18®Sport Cub S Limited WarrantyWhat this Warranty CoversHorizon Hobby, LLC (Horizon) warrants to the original purchaser that the product purchased (

RTFEN19Sport Cub S the shipping carton. NOTICE: Do not ship LiPo batteries to Horizon. If you have any issue with a LiPo battery, please contact the a

EN2®Sport Cub S WARNING: Read the ENTIRE instruction manual to become familiar with the features of the product before operating. Failure to operate

EN20®Sport Cub S Instructions for disposal of WEEE by users in the European UnionThis product must not be disposed of with other waste. Instead, it i

78®Sport Cub S Replacement Parts – Ersatzteile – – Pièces de rechange – Pezzi di ricambio –Part # • Nummer Numéro • CodiceDescription Beschreibung Des

RTF79Sport Cub S Optional Parts – Optionale Bauteile – – Pièces optionnelles – Pezzi opzionali –Part # • Nummer Numéro • CodiceDescription Beschreibun

© 2014 Horizon Hobby, LLC.HobbyZone, the HobbyZone logo, SAFE, the SAFE logo, Celectra, Bind-N-Fly, the BNF logo, DSM, DSM2, DSMX, ModelMatch, and the

RTFEN3Sport Cub S Ultra Micro Sport CubUSB Charger Transmitter (RTF Only)150 mAh 3.7V Li-Po BatteryAA Alkaline Batteries (4) (RTF Only)Included in the

EN4®Sport Cub S Remove the battery cover. Install the four included batteries (noting proper polarity) and reinstall the battery cover.TransmitterLow

RTFEN5Sport Cub S IMPORTANT: The installed receiver has been programmed for operation specifi cally in this aircraft.To operate the SAFE system in this

EN6®Sport Cub S Beginner Mode (with Self leveling):Pitch (nose up and down) and Roll (wing tips up and down) angles are limited to help you keep t

RTFEN7Sport Cub S The included USB charger has been designed to safely charge the included Li-Po battery.CAUTION: All instructions and warnings must b

EN8®Sport Cub S Installing the Flight BatteryYour Sport Cub RTF transmitter comes pre-bound to the aircraft, so binding should not be necessary. Keep

RTFEN9Sport Cub S Control Direction TestUp Elevator (climb)Down Elevator (descend)Rudder LeftRudder Right1. Place the aircraft into Experienced mode
